INCH-POUND
MIL-DTL-14636/9C
1 March 2006
SUPERSEDING
MIL-P-14636/9B
15 May 1997
DETAIL SPECIFICATION SHEET
PLAQUE, AIR FORCE CHAPLAIN SERVICE, AIR FORCE
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-14636.
DIMENSIONS: As shown on figure 1 and as specified herein.
DIAMETER: 15 inches (REF)
NOTES:
1. Finished plaque shall have a gloss finish.
2. The term (REF) refers to measurements taken from the Government
furnished plaster model.
3. The eagle body, wings and legs shall be shaded using a wipe
technique. The base coat (*) shall be allowed to dry before the detail
color (**) is applied. The detail color shall then be wiped while still
wet creating a shading effect in the recessed areas.
4.
The colors for the plaque shall be as listed in the chart below.
AMSC N/A
1 of 3
FSC 9905
