MIL-DTL-20633D
3.4 Materials and components. Materials and components shall be as specified on the drawings
referenced herein. When substitute components are proposed, the contractor shall submit to the
responsible agency a listing of all substitute components, samples of the components, and
supporting data which proves the functional equivalence and design compatibility of the items.
Approval of the submitted listing authorizes construction of the first article.
3.5 Construction. Construction shall conform in all respects to the drawings listed in section 2
and as specified herein.
4 VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as
follows:
a. First article inspection (see 4.2)
b. Quality Conformance inspection (see 4.3)
c. Inspection of packaging (see 4.4)
4.2 First article inspection. When specified (see 6.2(e)), a random sample shall be subject to first
article inspection. The contractor shall furnish to the Government one or more safe-lane and
mined-area marking signs and mine markers, as specified by the contract. Unless otherwise
specified (see 6.2(e)), all examination and test shall be conducted by the contractor and subjected
to surveillance and approval by the Government. The signs and markers shall be examined for the
characteristics in table I. Failure of first article signs and markers to meet examination criteria of
table I shall be cause for rejection of the first article signs and markers. Any failure shall be cause
for the Government to reject any production signs and markers until the contractor has provided
acceptable evidence that the defects have been eliminated.
Table I. Examination characteristics.
Defects
Components missing or not assembled as specified.
Dimensions not as specified.
Materials not as specified.
Workmanship not as specified.
4.3 Quality conformance inspection. Samples shall be examined for the defects listed in table I.
Sampling for examination shall be in accordance with ANSI/ASQC Z1.4. Lot size shall be as
specified (see 6.2(f)). The unit of product is one safe-lane sign, one mined-area sign, and one
mine marker.
3
