MIL-DTL-15024F

discoloration, or visible evidence of fungus shall constitute a failure. Slight discoloration or

fading of anodized colors which do not exhibit a deleterious effect on legibility is permissible.

TABLE III. Classification of Defects.

Categories

Defects

Major:

101

Finish blistered, flaked, peeled, chipped, cracked, softened, or not as

specified.

102

Burred, slivered, splintered, split, delaminated, or injurious to personnel.

103

Incorrect color.

104

Illegible.

105

Inscription or description does not conform to specification sheet or contract

requirements.

106

Materials not as specified.

107

Dimensions do not meet requirements.

4.3.1.1 Temperature test. The finished item shall be tested in accordance with

MIL-STD-202, Method 107, Condition B, for three cycles.

4.3.1.2 Moisture resistance test. The finished item mounted to a test surface shall be tested

in accordance with MIL-STD-202, Method 106.

4.3.1.3 Solvent resistance test. The finished item mounted to a test surface shall be tested in

accordance with MIL-STD-202, Method 215. The face of the plate shall be brushed.

4.3.1.4 Salt spray test. The finished item mounted to a test surface shall be tested in

accordance with ASTM-B117.
