MIL-DTL-19834C
TABLE II. Color styles.
Background
Characters
Style
FED-STD-595
FED-STD-595
Color
Color
Color Number
Color Number
37038
Black
White
37875
I
37875
White
Black
37038
II
-
Natural
Black
37038
III
37038
Black
Natural
-
IV
37875
White
24087
Olive drab
V
37875
White
21105
Red
VI
37038
Black
23655
Yellow
VII
-
Natural
21105
VIII
Red
-
Natural
12197
IX
Orange
NOTE: When plates are designed with blank spaces or pads upon which
additional marking will be added at a later time, the background
and character color requirements do not apply to the pads or
characters marked thereon.
3.7 Finish. Finish shall be such that identification plates shall conform to the requirements of this
specification. If surfaces are anodized, they shall be anodized in accordance with type I or type II of MIL-A-8625
before adhesive is applied. The anodizing of the edge surfaces or surface under the adhesive of identification plates
is optional. Whether anodized or not, name plate shall conform to abrasion test requirement.
3.8 Workmanship. Identification plates shall meet the design and dimensional requirements of this
specification. All lines, numerals, and letters of finished identification plates shall be sharp and clear. All colors
shall be uniform. Identification plates shall have smooth edges and shall be free of blisters, cracks, sharp corners,
foreign matter or any other indications of defects (see 4.6.2).
4. VERIFICATION
4.1 Classification of inspections. The inspections specified herein are classified as follows:
(a) First article inspection (see 4.3).
(b) Conformance inspection (see 4.4).
4.2 Inspection conditions. Unless otherwise specified herein, all inspections shall be performed in
accordance with the test conditions specified in the general requirements of MIL-STD-202.
4.3 First article inspection. First article inspection shall be performed at a laboratory or contractor's facility
acceptable to the Government (see 6.3) on sample units produced with equipment and procedures normally used in
production.
4.3.1 Inspection routine. First article inspection of identification plates shall consist of the examination
and tests specified in table III on the samples as indicated therein, in the order shown.
6
